Product details of the blood culture flask assembly machine
Product Introduction
HONGREAT blood culture flask assembly machine is made of high-grade raw materials and manufactured by using cutting-edge technology in complete compliance with industry production standards. Customers can benefit from various performance superiorities of the product. The product keeps pace with the changing demand of customers and has a wide market application.
Blood Culture Bottle Automatic Assembly Production Machine
|
Main Technical Parameters
|
|
Bottles sorting
|
• Sorting bottles to the next station
|
|
Resin filling (3*5 nozzles)
|
• 3*5 nozzles, 5pcs every time
• Filling volume tolerance: 4±0.4g
|
|
Culture medium filling (6 sets
Peristaltic pump)
|
• Filling volume: 35ml±0.1mL
• With 6 pump
• Medium tank volume: 30L
|
|
Automatic gas-filling, vacuuming &
rubber adding (16 heads, with vibration bowl feeding)
|
• Automatic gas-filling & rubber adding
• Rubber to be sorted by vibration bowl
• Vacuum: ＜-95kpa
• Vacuum tolerance: ±5% (not include bottle itself tolerance);
• Number of times for gas-filling can be set on touch screen
|
|
Capping (with vibration bowl feeding)
|
• Cap to be sorted by vibration bowl
|
Tube loading -- Reverse tube detection -- Chemical filling (cell-free DNA/RNA liquid solution) -- Cap adding -- Vacuuming -- Test tube labeling (automatic removal for empty tube) --Packing (loading into foam tray) -- Sealing and shrink packing -- Finished product.
• Precision ceramic syringe pump for chemical filling, 10 nozzle. Volume can be adjusted on screen.
• Vacuum-assisted cap picking: capping unit + vacuum suction. Different from traditional plunger type cap picking method, avoid cap missing due to plunger wear, stability and reliability can reach 99.99%, more stable and durable.
Comparison of Vacuum Chamber
|
HONGREAT
|
Other Pump
|
|
![Blood Culture Flask Assembly Machine by HONGREAT 4]()
|
![Blood Culture Flask Assembly Machine by HONGREAT 5]()
|
|
• All-stainless steel integrated vacuum chamber to ensure no leakage for the vacuum, the service life exceeds 10 years.
|
Others use aluminum alloy spliced vacuum chamber, vacuum leaks after 2 years usage.
|
more than 20 years experience in manufacturing vacuum blood collection tube automatic production lines.
More than 8,000 square meters
Has 3 factories with a total area of more than 8,000 square meters production plant.
Already supported over 230 clients for their BCT production projects in 39 countries.
We have more than 18 patents in blood collection equipment.
Comparison of Vacuum Chamber
All-stainless steel integrated vacuum chamber to ensure no leakage for the vacuum, the service life exceeds 10 years.
Others use aluminum alloy spliced vacuum chamber, vacuum leaks after 2 years usage.
Comparison of Numerical Control Vacuum System & Proportional Valve Vacuum System
HONGREAT (SMC numerical control vacuum system)
• HONGREAT digital vacuum system, adjustable in units of Hpa, which is 10 times the accuracy of other vacuum systems. • Applied with SMC Japan vacuum sensor and control system. • HONGREAT digital vacuum system is stable and reliable after more than 10 years of verification and operation test.
• Choose old, low-cost proportional valve vacuum control system, accuracy cannot be guaranteed after aging.
12 month machine warranty (except vulnerable parts). Warranty time is based on goods receiving date or signing date of receipt form.
2
Is pre-setting function for production related parameters available?
Yes, available.
3
Can you make password protection for parameter setting for the machine, to avoid mis-operation?
Yes, we can do customization for your machine.
4
Do you provide machine onsite installation?
Yes, we provide on-site machine installation and debugging service.
Company Advantage
• After rapid development for years, HONGREAT has developed into a leading enterprise within the industry. We gain good economic and social benefits based on the advanced technology and good service.
• HONGREAT's development is guaranteed by the good external conditions, including superior geographical location, traffic convenience, and abundant resources.
• HONGREAT has experienced technicians and senior management experts to provide technical support for product development and innovation.
• HONGREAT has a sales network throughout the domestic and international markets.
Contact HONGREAT right now and enjoy the discount!
